Capacitor Discharge Ground Studs
Designed for both capacitor discharge stud welding and reliable electrical grounding points, CD grounding studs create mechanical and electrical connections for enclosures, panels, and industrial assemblies. Unlike clamps and other fasteners, capacitor discharge ground studs ensure the electrical system remains securely and continuously connected, increasing safety and enabling proper performance of sensitive electronics. Southern Stud Weld is a leader in the stud welding industry, providing one of the most comprehensive inventories of weld studs to suit various industrial applications.
Looking for an electrical grounding stud for your applications? Contact Southern Stud Weld, and we will be happy to recommend a solution that meets your requirements.
Looking for an electrical grounding stud for your applications? Contact Southern Stud Weld, and we will be happy to recommend a solution that meets your requirements.
CD Grounding Stud Types and Material Selection
For different electrical and mechanical applications, CD ground studs are available in multiple designs and materials to offer various features and benefits to meet your specific requirements:| Part Number | Product Name | Material | Features |
|---|---|---|---|
| 4016718 | Capacitor Discharge Grounding Stud / Spade Terminal Chuck | Not Specified | Dimensions for grounding applications; can connect spade terminals. |
| 4072200 | Capacitor Discharge Grounding Stud, Single Tab, Mild Steel (Spade Terminal) | Mild Steel | Single tab design for easy spade terminal attachment. |
| 4072014 | Capacitor Discharge Grounding Stud, Single Tab, Brass (Spade Terminal) | Brass | Single tab design; brass provides corrosion resistance and good conductivity. |
| 4072015 | Capacitor Discharge Grounding Stud, Double Tab, Mild Steel (Spade Terminal) | Mild Steel | Double tab design for stronger mechanical and electrical connections. |
Primary Uses of CD Ground Studs in Various Industries
Capacitor discharge grounding studs are used for electrical grounding, spade terminal connections, thin metal applications, as well as industrial and electronic assemblies, creating safe pathways to channel electrical current in the event of a fault. Their primary uses and applications across industries include:- Providing a permanent electrical grounding point for safety and functionality
- Utilizing various tab designs for easy attachment of spade terminals, including double tabs for extra security
- Ideal for thin sheet metal applications, as this process prevents warping or damage to thin materials
- Typically used in control panels, machinery housings, automotive applications, and electronic equipment
Electrical Grounding Stud Benefits for Capacitor Discharge Stud Welding
Providing a reliable, low-resistance electrical path to ground, CD grounding studs offer a range of benefits to stud welding operations. Their dedicated path for stray current prevents electrical shocks and increases operator safety, while creating a strong, permanent connection that won’t loosen over time, unlike a traditional fastener. Electrical grounding studs are highly versatile for various applications, delivering advantages that include:- Fast, reliable installation with capacitor discharge stud welding systems
- Low-heat weld to minimize distortion and preserve material integrity in thin sheets
- Strong electrical and mechanical connection solutions in one step
- Multiple material and tab options available to suit different application requirements
